1 Ton Battery Operated AGV To Türkiye Factory

DATE: 2024 - 10 - 23
Read: 91 次浏览
Share:

Türkiye customer ordered four AGV transporter trolleys with a designed load-bearing capacity of 1 ton. This type of AGV automated handling integrates intelligence, automation, high appearance and high configuration. It provides a movable platform for production line transportation. At the same time, in order to meet the needs of specific working conditions and production frequency, the customer chose a battery-powered design, so that automated guided cart can maintain stable, safe and effective operation during operation.





Industrial transfer trolley 20 tons can easily turn when carrying heavy loads, and is equipped with safety alarm lights and anti-collision systems to ensure transportation safety.

5 Aspects of Automatic Guided Vehicle



  • Navigation Method

AGV electric transporter adopts two navigation methods: laser navigation and QR code navigation, to achieve autonomous navigation and autonomous operation of industrial carts. Laser navigation has the advantages of high precision, strong adaptability and strong anti-interference ability, and is suitable for use in complex environments. QR code navigation has the advantages of low cost and flexible layout, which can meet the needs of users for different routes.



  • Wireless AP Module

In the AGV system, the wireless AP is used to realize wireless communication between automated guided vehicle and the control center or other equipment, ensure stability and real-time data transmission, and realize remote control. The host computer controls transfer trolley to move forward and backward, turn left and right, move vertically and horizontally, rotate on the spot, and walk diagonally to realize the M-shaped walking.



  • Operation Mode

Battery operated transfer trolley is equipped with two sets of 3 tons steering wheels as driving wheels and two sets of double-turn universal wheels as passive wheels, which can realize all-around travel. In addition to normal forward and backward movement, left and right turns, it can also realize vertical and horizontal movement, on-site rotation, diagonal movement and other modes to meet the transportation operations in a small space.



  • Hydraulic Device

The hydraulic lifting system is used to control the height of the cargo platform on the AGV to realize automatic loading and unloading of goods. The four-cylinder synchronous lifting stroke is 15 cm, and it also has an automatic leveling function. On flat sections or climbing sections, the table surface can be kept level continuously to ensure that the goods do not tilt and slide, ensuring the safety of the goods. This design enables transfer cart to adapt to shelves or workbenches of different heights, improving the flexibility and efficiency of handling operations.



  • Safety Devices

The laser obstacle avoidance radar is equipped at the diagonal corner. Material movement trolley will automatically stop when encountering an obstacle, and will automatically move after the obstacle is removed. Electric platform cart is equipped with a circle of edge touch alarms around it. When the alarm is triggered, transfer trolley will stop immediately. The sound and light integrated alarm light and intelligent voice broadcast remind the operator and passers-by to pay attention to avoid, ensuring the safety of goods, personnel, and automated guided cart.

Transfer Cart Details
Transfer Cart Details



In summary, AGV automated handling solution integrates a variety of technologies and functions, and has the capabilities of high-precision navigation, omnidirectional movement, wireless communication, voice prompts, safe obstacle avoidance, and flexible lifting, which can significantly improve the automation level and efficiency of handling operations! For more cases of transfer trolleys, see this article — 25 Ton Heavy Tow Trolley To Saudi Arabia.
